John Deere 6081 约翰迪尔 强鹿柴油机配件缸套组件

John Deere 6081 约翰迪尔 强鹿柴油机配件缸套组件，John Deere 6081 约翰迪尔 强鹿柴油机配件缸套组件技术支持，John Deere 6081 约翰迪尔 强鹿柴油机配件缸套组件价格规格资料查询，John Deere 6081 约翰迪尔 强鹿柴油机配件缸套组件哪里有，John Deere 6081 约翰迪尔 强鹿柴油机配件缸套组件多少钱，John Deere 6081 约翰迪尔 强鹿柴油机配件缸套组件联系电话
产品咨询

详细描述

John Deere 6081 High Compression Piston


PowerTech
 Series
Engine & Equipment Model
6081
8.1L Tier 2 & Tier 3 from ESN 200,000

High Compression Piston

4801

4803

Bore:
4.56 in 116 mm

Pin Ø:
1.8742 in (+/- .0002) = 47 mm

Engine Model Number:

6081HDW08

6081HDW09

6081HDW13

6081HRW25

6081HRW31

6081HRW32

6081HRW33

6081HRW34

6081HRW41

6081HRW42

6081HRW43

6081HT002

6081HT008

6081HTJ05

6081HTJ06

6081HTJ07

6081HTJ08

6081HZ009

Con Rod (m):
RE535555
Piston (m):
RE70688
RE64509

Applications

AGRICULTURAL
7710
Tractor
7810
Tractor
7820
Tractor
7920
Tractor
8120
Tractor
8120T
Tractor
8220
Tractor
8220T
Tractor
8320
Tractor
8320T
Tractor
8420
Tractor
8420T
Tractor
8520
Tractor
8520T
Tractor
CONSTRUCTION
330CLC
Excavator
370C
Excavator
608B
Feller Buncher
608S
Feller Buncher
753G
Feller Buncher
608L
Feller Buncher
703G
Feller Buncher
703JH
Tracked Harvester
753GL
Feller Buncher
753J
Feller Buncher
753JH
Feller Buncher
759G
Feller Buncher
759J
Feller Buncher
759JH
Feller Buncher
770D
Motor Grader
772D
Motor Grader
870D
Motor Grader
872D
Motor Grader
3554
Logger
Engine O/H Kit
TRE526727
(Click for Kit Contents)
Engine I/F Kit
TIK526727
(Click for Kit Contents)
Piston-Liner Kit
TRE64509
Consists of:
a)
TRE70688
b)
TRE503528
c)
TR57771
d)
TR116236
e)
TAR98850
f)
TE1343FN
Main Bearing
TRE529319
Std.
TRE534181
0.0115
Use 6
Thrust Bearing
TRE529320
Std.
TRE504199
0.0115
Use 1
Thrust Washer
TRE61253
Std.
Use 3, Order Qty 1
Con Rod Bearing
TR116081
Std.
TRE57167
0.0115
Use 6
1)
Front Seal
TAR49025
(5)
TRE543639
(5)
2)
Rear Seal
TRE520036
3)
Crankshaft, Gear
TR104587
4)
Crankshaft
TRE535300
(1)
TRE534314
(2)
5)
Ring Gear
TR28811
6)
Rear Gear
TR63326
1)
O/H Gasket Set
TRE527551
2)
Head Gasket Set
TRE527552
3)
Head Gasket
TRE55475
4)
Oil Pan Gasket
TR532464
(3)
TR520844
(4)
5)
Rocker Cover Seal
TR502598
TR502719
1)
Bush, Con Rod
TR74008
x6
2)
Bolt, Con Rod
TR501035
x12
3)
Bushing, Cam
TR87561
x4
4)
Con Rod
TRE535555
1)
Plug, Camshaft
TR82007
2)
Oil Cooler
TAR55394
3)
Tappet
TR110126
x12
4)
Tensioner, Belt
TRE518097
(6)
TRE68715
(6)
TRE57498
(6)
5)
Camshaft Kit
TRE57054
(7)
1)
Pump, Water
TRE521502
2)
O'ring Mount Kit
TRE509463

Valve Section

(Click i, mage to zoom the valve diagram.)

Valve, Intake
TR84618
Std.
TR93308
0.003
TR93312
0.015
Valve, Exhaust
TR84619
Std.
TR93311
0.003
TR93313
0.015
1)
Insert, Valve In
TR121193
Std.
2)
Insert, Valve Ex
TR119132
Std.
1)
Cap, Valve
TT20129
2)
Lock, Valve
TT20077
3)
Shield, Valve
TR501640
x6
1)
Spring, Valve
TR91822
(7)
TR502187
(8)
1)
Thermostat
TAR48675
180° F
2)
Thermostat Housing Seal
TR136063
Pump, Oil
<, /DIV>
TRE60622
1)
Oil Pressure Sensor
TRE167207
(6)
2)
Water Temp Sensor
TRE52722
(6)
3)
Crankshaft Sensor
TRE519144
(6)
4)
Temperature Sensor
TRE522823
(6)

(1) With helical oil pump drive gear. Do not use with HPCR fuel system.

(2) With straight oil pump drive gear.

(3) Paper Gasket.

(4) Metal/Rubber Gasket.

(5) Both Front Seal are included in the Kit.

(6) Check application for proper usage.

(7) Camshaft marked R120872.
