约翰迪尔John Deere 3.164柴油发动机维修保养替代配件

湖南英珀威机械有限公司专业的约翰迪尔John Deere 3.164柴油发动机维修保养替代配件销售维修保养服务代理商，服务热线：15580888444
产品咨询

详细描述

John Deere 3.164 Small Pin, O'rings on Block


300
 Series
Engine & Equipment Model
3.164
To ESN 179,601

Small Pin, O’rings on Block

Bore:
4.02 in 102 mm

Pin Ø:
1.1878 in (+/- .0001) = 30mm

Con Rod (m):
T20007
R81410
Piston (m):
AR87736
AR90550

Applications

AGRICULTURAL
1420
1520
1530
CONSTRUCTION
350B
1)
Engine O/H Kit
TOK3593
(Click for Kit Contents)
2)
Engine I/F Kit
TIK3593
(Click for Kit Contents)
Piston-Liner Kit
TAR71593
Consists of:
a)
TAR78310
b)
TAR55759
c)
TT26149
d)
TR116463
e)
TAR71618
f)
TR51112
Main Bearing
TRE27352
Std.
TRE27353
0.010
TRE27360
0.020
TRE27368
0.030
Use 3
Thrust Bearing
TAT21139
Std.
TAT21132
0.010
TAT21134
0.020
TAT21136
0.030
Use 1
Con Rod Bearing
TRE27348
Std.
TRE27349
0.010
TRE27358
0.020
TRE27364
0.030
Use 3
1)
Front Seal
,
TAR67942
2)
Rear Seal
TRE44574
3)
Crankshaft
TAT18031
4)
Crankshaft, Gear
TT20094
5)
Ring Gear
TR114282
(142T)
1)
O/H Gasket Set
TRE501578
2)
Head Gasket Set
TRE38850
3)
Head Gasket
TR97356
4)
Oil Pan Gasket
TR97341
5)
Rocker Cover Gsk
TR75729
1)
Bush, Con Rod
TT23471
x3
2)
Bolt, Con Rod
TR74194
x6
(3)
3)
Camshaft Kit
TRE55900
4)
Con Rod
TAT18005
1)
Pump, Oil
TRE55343
2)
Oil Cooler
TRE31929
(2)
3)
Rocker Arm
TRE31973
4)
Rocker Shaft
TR54985
5)
Pump, Oil Tube
TR113752
1)
Lower Gear
TAT24252
2)
Lower Bushing
TT26321
3)
Upper Gear
TAT18009
4)
Upper Bushing
TT20034
5)
Cam. Follower
TT20073
x6
6)
Cam. Gear
TT20070
7)
Camshaft Kit
TRE55900
(5)

Valve Section

(Click image to zoom the valve diagram.)

Valve, Intake
TR79623
Std.
TR79628
0.003
TR79629
0.015
Valve, Exhaust
TR79624
Std.
TR79625
0.003
TR79626
0.015
1)
Insert, Valve In
TR73064
Std.
2)
Insert, Valve Ex
TR51734
Std.
1)
Cap, Valve
TT20129
2)
Lock, Valve
TT20077
1)
Spring, Valve
TR26125
2)
Rotator, Valve
TRE11410
3)
O’ring, Valve
TR87627
1)
Thermostat
TRE33705
180° F
(1)
2)
Thermostat Cover
TT23620
Fuel Transfer Pump
TRE42211
Water Pump Repair Kit
Without Impeller
TRE19507
With Impeller
TRE62658
Water Pump
TAT27018
(4)
1)
Seal, Injector
TR60746
TR48000
2)
Injector, Pencil
TAR89564
3)
Kit, Grommet
TMX504
4)
Cap
TAT27622
5)
Washer
TT29539

(1) Do not use with Housing (m) R54096, R70741, R74549.

(2) Conversion Kit TMX386: Available Consists of:  TT31306 X1 Nipple  TR99802 X2 Hose.

(3) Use TR74194 with C.Rod (m) T20007; use TR80033 with C.Rod (m) R81410.

(4) (m) R48997, (m) R51039.

(5) Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957 and RE522311.
