john deere约翰迪尔强鹿柴油机缸盖
配件详情
麦克福斯约翰迪尔发动机零配件
|
|
|
约翰迪尔 4045 4.5T/H 活塞（米）RE515037 排放 2 & 3 (2)
|
|
||||||||||||||||||||||||||||
（1）1件组合式密封和穿套; 替换TRE59810，RE538097。
（2）在曲轴加工过程中必须保持正确的轴承轴颈半径，以确保正确操作。
RE523502、RE59588、RE540301、RE528929、RE515843、RE515895、RE507670、RE70957、RE70957、RE70960、RE508322、RE504009、RE70474、RE70960、RE523501、RE507943、RE528929、RE507236、RE528532、RE68470、RE51447、RE54092、RE505745、RE503226、RE509025、RE540301 SE501419、SE501844、RE520437/
美国强鹿JOHN DEERE柴油发电机常见型号配件：
3029DF128、4039DF008、4045TF258、6068TF158、6068TF258、6068HF158、6068HF258、6081HF001A、6081HF001B、6125HF070A、6125HF070B,6125HF070C。5030HF270A 、6059TF005、6135H458。4045DFM70, 4045TFM75, 6068TFM75, 6068TFM76powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2307 pn=273 p r o o f p r o o f fan drive 23bg 23bg 23bg 23bg 23bg 23bg rgp7589 -un-20apr01 this parts listing is continued 2300-2308 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=274 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1" r116466 plug 1 xxxxxx- 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 (a) 5 r62191 snap ring ar (b) r62192 snap ring ar (c) r62193 snap ring ar (d) r62194 snap ring ar 6 r132175 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69358 housing 1 (marked r129057) fan height 353mm (13.90") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2309 pn=275 p r o o f p r o o f fan drive 23bj 23bj 23bj 23bj 23bj 23bj rgp7590 -un-20apr01 this parts listing is continued 2300-2310 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=276 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1", (use with r129809) r116466 plug 1 xxxxxx- (use with r504671) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69357 housing 1 -xxxxxx (marked r129057) fan height 353mm (13.90") re515784 housing 1 xxxxxx- (marked r129057) 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 -xxxxxx r503823 pulley 1 xxxxxx- 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2311 pn=277 p r o o f p r o o f fan drive 23bl 23bl 23bl 23bl 23bl 23bl rgp7591 -un-20apr01 this parts listing is continued 2300-2312 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=278 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1", (use with r129809) r116466 plug 1 xxxxxx- (use with r504671) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r128972 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re64657 housing 1 (marked r129057) fan height 353mm (13.90") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2313 pn=279 p r o o f p r o o f fan drive 23cc 23cc 23cc 23cc 23cc 23cc rgp7592 -un-20apr01 this parts listing is continued 2300-2314 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=280 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1", (use with r129809) r116466 plug 1 xxxxxx- (use with r504671) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r128834 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re67556 housing 1 (marked r129057) fan height 427mm (16.81") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r130389 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2315 pn=281 p r o o f p r o o f fan drive 23ce 23ce 23ce 23ce 23ce 23ce rgp7593 -un-20apr01 this parts listing is continued 2300-2316 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=282 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1" r116466 plug 1 xxxxxx- 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r132956 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69359 housing 1 (marked r129057) fan height 427mm (16.81") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2317 pn=283 p r o o f p r o o f fan drive 23cg 23cg 23cg 23cg 23cg 23cg rgp7594 -un-20apr01 this parts listing is continued 2300-2318 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=284 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1" r116466 plug 1 xxxxxx- 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r132175 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69358 housing 1 (marked r129057) fan height 427mm (16.81") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2319 pn=285 p r o o f p r o o f fan drive 23cj 23cj 23cj 23cj 23cj 23cj rgp7590 -un-20apr01 this parts listing is continued 2300-2320 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=286 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1" r116466 plug 1 xxxxxx- 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69357 housing 1 -xxxxxx (marked r129057) fan height 427mm (16.81") re515784 housing 1 xxxxxx- (marked r129057) fan height 427mm (16.81") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2321 pn=287 p r o o f p r o o f fan drive 23cl 23cl 23cl 23cl 23cl 23cl rgp7591 -un-20apr01 this parts listing is continued 2300-2322 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=288 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1" r116466 plug 1 xxxxxx- 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r128972 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re64657 housing 1 (marked r129057) fan height 427mm (16.81") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2323 pn=289 p r o o f p r o o f fan drive 23dc 23dc 23dc 23dc 23dc 23dc rgp7592 -un-20apr01 this parts listing is continued 2300-2324 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=290 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1" r116466 plug 1 xxxxxx- 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r128834 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re67556 housing 1 (marked r129057) fan height 464mm (18.27") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r130389 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2325 pn=291 p r o o f p r o o f fan drive 23de (esn -030083) 23de (esn -030083) 23de (esn -030083) 23de (esn -030083) 23de (esn -030083) 23de (esn -030083) rgp7575 -un-19apr01 this parts listing is continued 2300-2325a powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=292 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 1" 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r132956 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69359 housing 1 (marked r129057) fan height 353mm (13.90") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re70535 tightener 1 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2325b pn=293 p r o o f p r o o f fan drive 23de (esn 030084-031638) 23de (esn 030084-031638) 23de (esn 030084-031638) 23de (esn 030084-031638) 23de (esn 030084-031638) 23de (esn 030084-031638) rgp7595 -un-20apr01 this parts listing is continued 2300-2326 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=294 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 (sub for re70535, this application) 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r132956 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 12 re501133 idler 1 (sub for re65849) 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 (sub for re64442) 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2327 pn=295 p r o o f p r o o f fan drive 23de (esn 031639- ) 23de (esn 031639- ) 23de (esn 031639- ) 23de (esn 031639- ) 23de (esn 031639- ) 23de (esn 031639- ) rgp7575 -un-19apr01 this parts listing is continued 2300-2327a powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=296 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1", (use with r129809) r116466 plug 1 xxxxxx- (use with r504671) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r132956 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69359 housing 1 (marked r129057) fan height 353mm (13.90") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2327b pn=297 p r o o f p r o o f fan drive 23dg (esn -030083) 23dg (esn -030083) 23dg (esn -030083) 23dg (esn -030083) 23dg (esn -030083) 23dg (esn -030083) rgp7575 -un-19apr01 this parts listing is continued 2300-2327c powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=298 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 1" 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r132175 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69358 housing 1 (marked r129057) fan height 353mm (13.90") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2327d pn=299 p r o o f p r o o f fan drive 23dg (esn 030084-031638) 23dg (esn 030084-031638) 23dg (esn 030084-031638) 23dg (esn 030084-031638) 23dg (esn 030084-031638) 23dg (esn 030084-031638) rgp7608 -un-23apr01 this parts listing is continued 2300-2328 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=300 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 (sub for re70535) 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r132175 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 12 re501133 idler 1 (sub for re65849) 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 (sub for re64442) 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2329 pn=301 p r o o f p r o o f fan drive 23dg (esn 031639- ) 23dg (esn 031639- ) 23dg (esn 031639- ) 23dg (esn 031639- ) 23dg (esn 031639- ) 23dg (esn 031639- ) rgp7575 -un-19apr01 this parts listing is continued 2300-2329a powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=302 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1", (use with r129809) r116466 plug 1 xxxxxx- (use with r504671) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r132175 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69358 housing 1 (marked r129057) 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r504671 cover 1 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2329b pn=303 p r o o f p r o o f fan drive 23dj (esn -030083) 23dj (esn -030083) 23dj (esn -030083) 23dj (esn -030083) 23dj (esn -030083) 23dj (esn -030083) rgp7575 -un-19apr01 this parts listing is continued 2300-2329c powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=304 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 1" 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r125200 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69357 housing 1 (marked r129057) 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 (this application only) 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r133175 bracket 1 24 19m7785 screw 2 25 r129809 cover 1 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2329d pn=305 p r o o f p r o o f fan drive 23dj (esn 030084-031638) 23dj (esn 030084-031638) 23dj (esn 030084-031638) 23dj (esn 030084-031638) 23dj (esn 030084-031638) 23dj (esn 030084-031638) rgp7608 -un-23apr01 this parts listing is continued 2300-2330 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=306 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 (sub for re70535, this application) 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r125200 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 12 re501133 idler 1 (sub for re65849) 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 (sub for re64442) 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 r116466 plug 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2331 pn=307 p r o o f p r o o f fan drive 23dj (esn 031639- ) 23dj (esn 031639- ) 23dj (esn 031639- ) 23dj (esn 031639- ) 23dj (esn 031639- ) 23dj (esn 031639- ) rgp7590 -un-20apr01 this parts listing is continued 2300-2331a powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=308 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx r116466 plug 1 xxxxxx- (use with r129809) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69357 housing 1 -xxxxxx (marked r129057) 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2331b pn=309 p r o o f p r o o f fan drive 23dk (esn -031638) 23dk (esn -031638) 23dk (esn -031638) 23dk (esn -031638) 23dk (esn -031638) 23dk (esn -031638) rgp7608 -un-23apr01 this parts listing is continued 2300-2332 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=310 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re506352 tightener 1 2 19m7810 screw 1 m10 x 80 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 12 re501133 idler 1 (sub for re65849) 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 (sub for re64442) 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2333 pn=311 p r o o f p r o o f fan drive 23dk (ens 031639- ) 23dk (ens 031639- ) 23dk (ens 031639- ) 23dk (ens 031639- ) 23dk (ens 031639- ) 23dk (ens 031639- ) rgp8371 -un-07dec01 this parts listing is continued 2300-2333a powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=312 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 r129809 cover 1 -xxxxxx (code 7700) r504671 cover 1 xxxxxx- (code 7700) 2 19m7836 screw 1 xxxxxx- m10 x 110 3 re506352 tightener 1 4 19m7810 screw 1 m10 x 80 5 19m7786 screw 2 xxxxxx- m10 x 30 6 15h686 pipe plug 1 -xxxxxx 1" r116466 plug 1 xxxxxx- 7 jd10329 ball bearing 2 8 r63987 shaft 1 9 re20768 seal 1 10 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 11 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 12 t20217 washer 1 13 19h1815 cap screw 1 1/2" x 1-1/4" 14 re69357 housing 1 (marked r129057) 15 19m7818 screw 1 m12 x 80 16 r133313 bracket 1 17 19m8551 screw 1 m10 x 25 18 r500320 spacer 1 19 re501133 idler 1 20 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 21 r99590 cover 1 22 19m7811 screw 1 m10 x 90 23 19m7785 screw 1 m10 x 25 24 re170083 tightener 1 (sub for re64442) 25 19m7785 screw 2 xxxxxx- m10 x 25 26 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2333b pn=313 p r o o f p r o o f fan drive 23dl (esn -030083) 23dl (esn -030083) 23dl (esn -030083) 23dl (esn -030083) 23dl (esn -030083) 23dl (esn -030083) rgp7575 -un-19apr01 this parts listing is continued 2300-2333c powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=314 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 1", (use with r129809) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r128972 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69357 housing 1 (marked r129057) fan height 353mm (13.90") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2333d pn=315 p r o o f p r o o f fan drive 23dl (esn 030084-031638) 23dl (esn 030084-031638) 23dl (esn 030084-031638) 23dl (esn 030084-031638) 23dl (esn 030084-031638) 23dl (esn 030084-031638) rgp7608 -un-23apr01 this parts listing is continued 2300-2334 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=316 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 (sub for re70535, this application) 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r128972 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 12 re501133 idler 1 (sub for re65849) 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 (sub for re64442, this application) 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 r116466 plug 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2335 pn=317 p r o o f p r o o f fan drive 23dl (esn (031639- ) 23dl (esn (031639- ) 23dl (esn (031639- ) 23dl (esn (031639- ) 23dl (esn (031639- ) 23dl (esn (031639- ) rgp7590 -un-20apr01 this parts listing is continued 2300-2335a powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=318 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 15h686 pipe plug 1 -xxxxxx 1", (use with r129809) r116466 plug 1 xxxxxx- (use with r504671) 2 jd10329 ball bearing 2 3 r63987 shaft 1 4 re20768 seal 1 5 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 6 r128972 pulley 1 7 t20217 washer 1 8 19h1815 cap screw 1 1/2" x 1-1/4" 9 re69357 housing 1 (marked r129057) fan height 353mm (13.90") 10 19m7811 screw 1 m10 x 90 11 19m7785 screw 1 m10 x 25 12 re170083 tightener 1 (sub for re64442) 13 r99590 cover 1 14 19m8114 screw 1 -034147 m10 x 70, (sub r130589, this application) r130589 screw 1 034148- 15 re501133 idler 1 16 r500320 spacer 1 17 19m7818 screw 4 m12 x 80 18 19m7785 screw 2 m10 x 25 19 19m8551 screw 1 m10 x 25 20 r133313 bracket 1 21 re170084 tightener 1 (sub for re70535, this application) 22 19m7810 screw 1 m10 x 80, (tab on side) 23 r503782 bracket 1 (sub for r133175) 24 19m7785 screw 2 25 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 26 19m7836 screw 1 m10 x 110 27 19m7786 screw 2 m10 x 30 28 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (17-dec-02) 2300-2335b pn=319 p r o o f p r o o f fan drive 23gb 23gb 23gb 23gb 23gb 23gb rgp8043 -un-15aug01 engine key part no. part name qty serial no. remarks 1 19m7836 screw 1 m10 x 110 2 19m7786 screw 2 m10 x 30 3 19m7812 screw 6 m10 x 100 4 r129809 cover 1 -xxxxxx r504671 cover 1 xxxxxx- 2300-2336 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=320 p r o o f p r o o f fan drive memoranda memoranda memoranda memoranda memoranda memoranda powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2337 pn=321 p r o o f p r o o f fan drive 231j 231j 231j 231j 231j 231j rgp7572 -un-25jul01 this parts listing is continued 2300-2338 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=322 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 m10 x 70 12 re501133 idler 1 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 16 19m7785 screw 1 m10 x 25 17 r504677 cover 1 15h686 pipe plug 1 1", (use with r504677) 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2339 pn=323 p r o o f p r o o f fan drive 231l 231l 231l 231l 231l 231l rgp7572 -un-25jul01 this parts listing is continued 2300-2340 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=324 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r128972 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 m10 x 70 12 re501133 idler 1 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 16 19m7785 screw 1 m10 x 25 17 r504677 cover 1 15h686 pipe plug 1 1", (use with r504677) 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2341 pn=325 p r o o f p r o o f fan drive 234e 234e 234e 234e 234e 234e rgp7608 -un-23apr01 this parts listing is continued 2300-2342 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=326 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r132956 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 m10 x 70 12 re501133 idler 1 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 r116466 plug 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2343 pn=327 p r o o f p r o o f fan drive 234g 234g 234g 234g 234g 234g rgp7608 -un-23apr01 this parts listing is continued 2300-2344 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=328 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r132175 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 m10 x 70 12 re501133 idler 1 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 r116466 plug 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2345 pn=329 p r o o f p r o o f fan drive 234j 234j 234j 234j 234j 234j rgp7608 -un-23apr01 this parts listing is continued 2300-2346 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=330 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re170084 tightener 1 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 m10 x 70 12 re501133 idler 1 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 r116466 plug 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2347 pn=331 p r o o f p r o o f fan drive 234k 234k 234k 234k 234k 234k rgp7608 -un-23apr01 this parts listing is continued 2300-2348 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=332 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re506352 tightener 1 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r125200 pulley 1 -xxxxxx r503823 pulley 1 xxxxxx- 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 m10 x 70 12 re501133 idler 1 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 r116466 plug 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2349 pn=333 p r o o f p r o o f fan drive 234l 234l 234l 234l 234l 234l rgp7608 -un-23apr01 this parts listing is continued 2300-2350 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=334 p r o o f p r o o f fan drive engine key part no. part name qty serial no. remarks 1 re506352 tightener 1 2 19m7810 screw 1 3 jd10329 ball bearing 2 4 r63987 shaft 1 5 re20768 seal 1 6 r62191 snap ring ar (a) r62192 snap ring ar (b) r62193 snap ring ar (c) r62194 snap ring ar (d) 7 r128972 pulley 1 8 t20217 washer 1 9 19h1815 cap screw 1 1/2" x 1-1/4" 10 r99590 cover 1 11 19m8114 screw 1 m10 x 70 12 re501133 idler 1 13 r500320 spacer 1 14 19m7811 screw 1 m10 x 90 15 re170083 tightener 1 16 19m7785 screw 1 m10 x 25 17 r502659 cover 1 r116466 plug 1 18 19m7836 screw 1 m10 x 110 19 19m7786 screw 2 m10 x 30 20 19m7812 screw 6 m10 x 100 (a) red (b) green rouge vert rot gruen rosso verde rojas verde roett groen (c) blue (d) white bleu blanc blau weiss blu bianco azul blanco blaa vit powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2300-2351 pn=335 p r o o f p r o o f fan drive memoranda memoranda memoranda memoranda memoranda memoranda 2300-2652 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=336 p r o o f p r o o f belts sectional index index de section gruppenindex indice della sezione indice de seccion gruppsforteckning rgp8052 -un-15aug01 2401 - 2402 - 2403 - 2404 - 2405 - 2406 - 2407 - 2408 - 2409 - 2410 - 2411 - 2412 - 2413 - 2414 - 2415 - 2416 - 2417 - 2418 - 2419 - 2420 - 2421 - 2422 - 2423 - 2424 - 2425 - 2426 - 2427 - 2428 - 2429 - 2430 - 2431 - 2432 - 2433 - 2434 - 2435 - 2498 - this parts listing is continued powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2400-a01 pn=337 p r o o f p r o o f belts sectional index index de section gruppenindex indice della sezione indice de seccion gruppsforteckning 2401 - 2402 - 2403 - 2404 - 2405 - 2406 - 2407 - 2408 - 2409 - 2410 - 2411 - 2412 - 2413 - 2414 - 2415 - 2416 - 2417 - 2418 - 2419 - 2420 - 2421 - 2422 - 2423 - 2424 - 2425 - 2426 - 2427 - 2428 - 2429 - 2430 - 2431 - 2432 - 2433 - 2434 - 2435 - 2498 - 2400-a02 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-dec-00) pn=338 p r o o f p r o o f belts memoranda memoranda memoranda memoranda memoranda memoranda powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-dec-00) 2400-2401 pn=339 p r o o f p r o o f belts 2401 2401 2401 2401 2401 2401 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r131083 v-belt 1 60.24" (12 rib) 2 r134638 v-belt 1 54.5" (8 rib) 2400-2402 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-dec-00) pn=340 p r o o f p r o o f belts 2402 2402 2402 2402 2402 2402 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r133693 v-belt 1 2 r133704 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-dec-00) 2400-2403 pn=341 p r o o f p r o o f belts 2403 2403 2403 2403 2403 2403 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r128806 v-belt 1 r133694 v-belt 1 2400-2404 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=342 p r o o f p r o o f belts 2404 2404 2404 2404 2404 2404 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r133695 v-belt 1 r502461 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) 2400-2405 pn=343 p r o o f p r o o f belts 2405 2405 2405 2405 2405 2405 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r130478 v-belt 1 r135681 v-belt 1 2400-2406 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=344 p r o o f p r o o f belts 2406 2406 2406 2406 2406 2406 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r133707 v-belt 1 r500616 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) 2400-2407 pn=345 p r o o f p r o o f belts 2407 2407 2407 2407 2407 2407 rgp7154 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r129083 v-belt 1 6 r131083 v-belt 1 2400-2408 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=346 p r o o f p r o o f belts 2408 2408 2408 2408 2408 2408 rgp7154 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r133697 v-belt 1 6 r133704 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2400-2409 pn=347 p r o o f p r o o f belts 2409 2409 2409 2409 2409 2409 rgp7157 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r135607 v-belt 1 6 r130478 v-belt 1 2400-2410 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=348 p r o o f p r o o f belts 2410 2410 2410 2410 2410 2410 rgp7154 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r135591 v-belt 1 6 r128806 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2400-2411 pn=349 p r o o f p r o o f belts 2411 2411 2411 2411 2411 2411 rgp7154 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r135680 v-belt 1 6 r502461 v-belt 1 2400-2412 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) pn=350 p r o o f p r o o f belts 2412 2412 2412 2412 2412 2412 rgp7157 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r133703 v-belt 1 6 r133707 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2400-2413 pn=351 p r o o f p r o o f belts 2413 2413 2413 2413 2413 2413 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r133700 v-belt 1 r133705 v-belt 1 2400-2414 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=352 p r o o f p r o o f belts 2414 2414 2414 2414 2414 2414 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r133701 v-belt 1 r133706 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) 2400-2415 pn=353 p r o o f p r o o f belts 2415 2415 2415 2415 2415 2415 rgp6068 -un-21aug00 engine key part no. part name qty serial no. remarks 1 r133696 v-belt 1 r502461 v-belt 1 2400-2416 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (22-aug-01) pn=354 p r o o f p r o o f belts 2416 2416 2416 2416 2416 2416 rgp7154 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r135602 v-belt 1 6 r133705 v-belt 1 powertech 12.5l 6125hf070 engine (waterloo) (esn 030000- ) pc2875 (09-jan-02) 2400-2417 pn=355 p r o o f p r o o f belts 2417 2417 2417 2417 2417 2417 rgp7154 -un-13dec00 engine key part no. part name qty serial no. remarks 1 r500320 spacer 1 2 re505265 idler 1 3 r107749 sleeve 1 -014926 (sub r502079) r502079 sleeve 1 014927- 4 19m7807 screw 1 5 r133702 v-belt 1 6 r133706 v-belt 1 2400-2418 遵义遵义县强鹿发动机缸套纯正配件的批发商,南阳社旗县帕金斯柴油滤芯se429b4商家,高雄小港9Y-6821卡特滤清器详细参数,日照莒县CAT3408柴油机配件气缸套组件缸套修理包5P8768电话多小?,合肥肥东县威尔逊/珀金斯柴油发电机活塞的价格,甘孜得荣县帕金斯柴油发动机机油滤芯价格怎么样?,喀什塔什珀金斯原厂配件批发纯正配件,内蒙古自治赤峰巴林右旗康明斯kta38-g2a的启动马达7折特卖,昭通彝良县卡特cat叶片泵销售公司,德州德城VOLVO海水泵正品配件,台中北屯南京沃尔沃VOLVO配件联系询价,important: a decrease in vacuum of 1 in. hg or more in five minutes indicates an excessive leak,/there is still liquid r– 134a in system. 3. follow machine technical manual&manufacturers instructions to evacuate system. specification evacuating system—required vacuum at sea level 94.4 kpa (0.9 bar) (28.6 in. hg) a. evacuate system for 15 minutes if ambient temperature is below 30°c (85°f), to remove air, nitrogen,&moisture. b. evacuate system for 30—45 minutes if ambient temperature is above 30°c (85°f), to remove air, nitrogen,&moisture. c. charge system. (see charge air conditioning system, this group.) ctm67 (24sep02) 70-9 oem engine acces***ies 092402 pn=373 air conditioning compres***s 70 10 dpsg,ouo1004,586 –19–01mar99–1/1 check refrigerant oil charge important: the appropriate oil charge for an air conditioning system is based on machine/system application. see your machine technical manual for specified oil quantities. 1. remove compres***. (see remove compres***, this group.) 2. remove manifold caps&drain oil. record amount. note: save oil if compres*** is new. 3. if more than 6 ml (0.2 fl oz) of oil was drained and appears normal,/any other components were replaced/flushed, see determine correct oil charge, this group. if less than 6 ml (0.2 fl oz) of oil was drained/if oil appears very black, perform the following: a. perform a volumetric efficiency test on compres*** to determine serviceable condition. flush with solvent to internally wash out oil if compres*** is serviceable. (see test volumetric efficiency, this group.) b. remove&clean expansion valve, but do not disassemble valve. c. remove&discard receiver-dryer. (see replace receiver-dryer, this group.) d. install a new receiver-dryer. e. flush&clean compres***. (see flush/clean air conditioning compres*** in this group.) f. flush complete system. (see machine technical manual.) g. install required oil. (see determine correct oil charge, this group.) h. connect all components. i. purge, evacuate,&charge system. (see procedures to purge evacuate&charge air conditioning system in this group.) note: if very black oil was observed when draining compres***, look for compres*** wear problems. this could mean worn internal parts like pistons&cylinders, which would require replacing the compres***. ctm67 (24sep02) 70-10 oem engine acces***ies 092402 pn=374 air conditioning compres***s 70 11 dpsg,ouo1004,587 –19–09may02–1/1 determine correct refrigerant oil charge note: determine amount of system oil charge prior to installation of compres***. important: the appropriate oil charge for an air conditioning system is based on machine/system application. additionally, a number of other factors will affect the amount of oil to add (i.e. whether/not the system/individual components were flushed, components were replaced, length of hoses changed, etc.). see your machine technical manual for determining correct oil charge. new compres***s are precharged with oil. the following capacities are for reference only. the actual oil charge for your system will vary by application. specification denso a/c compres*** (new)—approximate oil capacity 230 ml (7.8 fl oz) sanden a/c compres*** (new)—approximate oil capacity 299 ml (10.1 fl oz) important: use care adding oil. too much oil in the system will reduce maximum cooling capacity. too little oil will result in poor lubrication of the compres***, leading to early compres*** failure. do not leave the system/r–134a refrigerant oil containers open. refrigerant oil easily ab***bs moisture. do not spill r–134a refrigerant oil on acrylic/abs plastic. oil will deteriorate these materials rapidly. identify r–134a oil containers and measures to eliminate accidental mixing of different fluids. ctm67 (24sep02) 70-11 oem engine acces***ies 092402 pn=375 air conditioning compres***s 70 12 dpsg,ouo1004,588 –19–09may02–1/2 add refrigerant oil to pressurized system rw78177 –un–30oct98 a—needle valve d—injector end g—low pressure quick i—refrigerant container b—jto2129 injector e—low pressure valve connector c—hose end f—high pressure valve h—high pressure quick connector important: the appropriate oil charge for an air conditioning system is based on machine/system application. see your machine technical manual for determining correct oil charge. note: jt02129 air conditioning oil injector is designed to add up to 60 ml (2 fl oz) of refrigerant oil to a system that is already pressurized. a/c oil injector can also add oil if the system has no pressure/is under a vacuum. 1. close the needle valve (a) on the oil injector jto2129 (b). 2. remove the hose end (c) of injector. add up to 60 ml (2 fl oz) of refrigerant oil,&reinstall the end. 3. connect hose end of injector to a r–134a, 360 ml (12 fl oz) refrigerant supply can. 4. connect other end of injector (d) to the center hose of a gauge manifold set&bleed air from hoses, if necessary. 5. connect gauge manifold connector (g) to the suction fitting on the compres***/port on suction line,&gauge manifold connector (h) to the discharge connector fitting on the compres*** or port on discharge line. 6. operate engine&turn compres*** switch on. 7. open the suction side valve (e) on the gauge set and the valve on the refrigerant supply can (i). ctm67 (24sep02) 70-12 oem engine acces***ies 092402 pn=376 continued on next page air conditioning compres***s 70 13 dpsg,ouo1004,588 –19–09may02–2/2 8. hold injector upright with valve at the bottom. 9. open valve on injector for five seconds to force oil into the system. note: suction pressure will increase when oil enters the compres***,&decrease after oil has passed through the compres***. 10. open injector valve for five seconds to insure all oil has been forced into the system. 11. repeat steps 2—10 if additional oil is required. 12. close gauge set&refrigerant supply valves. slowly loosen the hoses to bleed off the pressure. 13. remove injector&cap both ends. ctm67 (24sep02) 70-13 oem engine acces***ies 092402 pn=377 air conditioning compres***s 70 14 dpsg,ouo1004,589 –19–09may02–1/1 charge air conditioning system note: see machine technical for the specified amount of r–134a refrigerant to add to system. note: bubbles may appear in sight glass (if equipped) when charging below 18°c (65°f) ambient temperature. bubbles will disappear when temperature rises. 1. evacuate system. (see evacuate air conditioning system, this group.) important: use only r–134a refrigerant recovery, recycling,&charging machines. prevent compres*** damage. do not mix r–134a equipment, refrigerant, and refrigerant oils with r-12 systems. 2. connect jt02045 r–134a refrigerant recovery, recycling,&charging station to charge system. note: jt02046 hfc134a refrigerant charging unit can be substituted for jt02045. 3. connect low-side hose (blue) to suction fitting on compres***/line. connect high-side hose (red) to discharge fitting on compres***/line. important: do not run engine. system must hold a minimum vacuum of 28.6 in. hg. deduct 1 in. hg from 29.9 in. for each 300 m (1000 ft) elevation above sea level. 4. charge the system. 5. weigh refrigerant supply tank&invert so refrigerant enters system as a liquid. 6. begin charging through discharge port/line first. as suction pressure nearly equals discharge pressure, open suction valve. important: close discharge valve on gauge manifold before starting engine and compres***, to prevent over pressurizing refrigerant container. 7. continue charging system to capacity. do not start engine until charging is completed. 8. close both gauge manifold valves&perform a system operational check. see procedure in machine technical manual. note: system checkout is normally done by running engine at low idle with a/c switch on for at least three minutes to fully circulate refrigerant and oil. ctm67 (24sep02) 70-14 oem engine acces***ies 092402 pn=378 air conditioning compres***s 70 15 dpsg,ouo1004,597 –19–01mar99–1/2 diagnosing air conditioning compres*** malfunctions note: the following diagnostic chart focuses on troubleshooting the compres*** only. for complete system diagnostics, refer to machine technical manual. note: sanden compres***s have no serviceable parts. use table as a guide to identify compres*** failure and replace compres*** as required. trouble cause indications remedy system produces no cooling loose/broken drive belt. visual inspection. replace drive belt/tighten to specifications. clutch coil/solenoid burned compres*** clutch/solenoid check current to clutch or out/disconnected. inoperative. solenoid. replace clutch if inoperative. compres*** partially/belt slips on pulley/remove compres*** for service completely seized. compres*** does not turn when/replacement. clutch is engaged. compres*** shaft seal leaking. clutch&front of compres*** replace compres*** shaft seal. oily. system low/out of refrigerant. compres*** reed valves only slight variation of manifold remove compres*** for service inoperative. gauge readings at any engine/replacement. speed. system will not produce compres*** clutch slipping. visual inspection. remove clutch assembly for sufficient cooling. service/replacement. low charge of refrigerant. bubbles in sight glass/high charge system. side gauge reading excessively low. compres*** noisy defective winding/improper visual inspection; clutch/repair/replace as necessary. connection in compres*** clutch solenoid vibrates. coil/solenoid. loose/excessively worn drive belt slips&is noisy. tighten/replace as necessary. belt. noisy clutch. may/may not slip. noisy when remove clutch for service or engaged. replace as necessary. compres*** noisy. loose mountings/worn parts in check mountings&repair. compres***. remove compres*** for service or replacement. compres*** oil level low. compres*** noisy. service compres*** with oil. ctm67 (24sep02) 70-15 oem engine acces***ies 092402 pn=379 continued on next page air conditioning compres***s 70 16 dpsg,ouo1004,597 –19–01mar99–2/2 trouble cause indications remedy excessive charge in system. rumbling noise/vibration in recover excess refrigerant. high pressure line. thumping noise in compres***. excessive suction&discharge pressures. low charge in system. bubbles in sight glass/low charge system with refrigerant. discharge pressure. ctm67 (24sep02) 70-16 oem engine acces***ies 092402 pn=380 air conditioning compres***s 70 17 ctm67 (24sep02) 70-17 oem engine acces***ies 092402 pn=381 air conditioning compres***s 70 18 dpsg,ouo1004,590 –19–01mar99–1/2 remove&install air conditioning compres*** rg9490 –un–25feb99 ctm67 (24sep02) 70-18 oem engine acces***ies 092402 pn=382 continued on next page air conditioning compres***s 70 19 dpsg,ouo1004,590 –19–01mar99–2/2 a—cap screw f—bracket k—sanden compres*** p—discharge port b—cover g—cap screw l—discharge port q—suction port c—cap screw h—washers m—suction port r—denso compres*** d—idler pulley i—bracket n—cap screw s—cap screw e—spacer j—cap screw o—spring pin note: sanden compres***s are not serviceable, while denso compres***s are serviceable. repair procedures for denso compres***s are covered later in this group. note: compres*** mounting assemblies vary; two types shown. 1. discharge system. (see discharge air conditioning system in this group. 2. remove belt from compres*** pulley. 3. disconnect compres*** clutch coil wire. 4. disconnect lines from ports (l&m)/(p&q). cap all lines&fittings to prevent contamination. 5. check refrigerant oil charge. (see check refrigerant oil charge in this group.) 6. flush complete system if compres*** failed internally due to damaged parts/seizure. (see flush air conditioning system in this group.) 7. add required oil to compres*** and/or system. (see determine refrigerant oil charge in this group.) important: spring pins, (if equipped), must be installed in cap screw holes of compres*** mounting bracket or misalignment can occur, causing belt damage. 8. check for spring pins (o), if equipped, in cap screw holes. 9. install compres***&tighten cap screws. 10. if removed, install idler pulley (d)&tighten cap screws to specifications. specification a/c compres*** idler pulley— torque. 55 n?m (40 lb-ft) 11. connect lines to ports (l&m)/(p&q). 12. connect clutch coil wire&install belt. 13. purge, evacuate&recharge system. (see procedures to purge, evacuate&charge the system in this group.) important: if a new compres***&clutch was installed, turn compres*** on&off (engine running) in one second intervals for five seconds (cycle five times in 5 seconds). this will burnish clutch&hub drive surfaces. ctm67 (24sep02) 70-19 oem engine acces***ies 092402 pn=383 air conditioning compres***s 70 20 dpsg,ouo1004,591 –19–09may02–1/2 test volumetric efficiency rg9550 –un–10may99 a—suction test port 1. drain oil from compres***&record amount. 2. remove front cover from compres*** pulley&rotate drive shaft 30 revolutions using a speed wrench and socket. 3. drain remaining oil from compres***&record amount. if no oil was removed, add two ounces of r–134a refrigerant oil in suction port. slowly roll compres*** in each direction at least two times. repeat steps 1—3. 4. secure compres*** in a vise with ports upward. 5. on denso compres***s, install jt02099 adapter and jt03194 cap from jt02098 fitting kit into suction port to close port of compres***. connect suction hose coupler of gauge set to suction test port (a) on manifold. on sanden compres***s, install jt03182 adapter into suction port of compres***. connect jt02108 hose to adapter. install jt02179 adapter to opposite end of hose, then attach to suction hose coupler of gauge set. 6. close gauge set suction side valve&open valve on suction hose coupler. 7. rotate compres*** drive shaft with speed wrench to obtain peak vacuum on low side gauge. check for even suction (no pulsing) while turning wrench at a slow rate to maintain peak vacuum (25 in. hg minimum). 8. stop rotating shaft&check leak-down time. compres*** should hold peak vacuum for a minimum of three seconds. if compres*** does not hold pressure for three seconds, inspect compres*** valve plates and cylinder walls for damage. repair/replace compres*** as required. 9. open suction port of compres*** to atmosphere. ctm67 (24sep02) 70-20 oem engine acces***ies 092402 pn=384 continued on next page air conditioning compres***s 70 21 dpsg,ouo1004,591 –19–09may02–2/2 rg9549 –un–10may99 a—discharge port 10. install jt02100 adapter (denso compres***s) or jt02154 (sanden compres***s) into discharge port (a) of compres***. install jt02108 hose and jt02179 adapter&connect to gauge set suction hose coupler. 11. close gauge set suction side valve. 12. rotate drive shaft no faster than two turns per second for six turns. 13. record pressure after six complete turns. pressure should be 380 kpa (3.8 bar) (55 psi) minimum. note: pressure normally leaks down when rotation s***. 14. continue to rotate compres*** at a uniform speed to obtain peak pressure. compression pressure should increase smoothly&should not vary more than 34 kpa (0.34 bar) (5 psi) at peak pressure. bleed off pressure&repeat steps 12, 13&14 four times. note: pressure varying more than 34 kpa (0.34 bar) (5 psi) indicates a leaking reed-valve/piston seal in compres***. repair/replace compres***. 15. leak test compres***. (see compres*** leakage test in this group). ctm67 (24sep02) 70-21 oem engine acces***ies 092402 pn=385 air conditioning compres***s 70 22 dpsg,ouo1004,582 –19–09may02–1/2 compres*** leakage test rw41334a –un–19dec97 a—suction port 1. remove front plate from compres*** pulley. 2. remove clutch hub&screw/nut. important: do not lose inner clutch hub shims. 3. on denso compres***s: install jt02099 adapter in suction port&jt02100 adapter in discharge port of compres***. cap discharge port using jt03194 cap. connect gauge set and/or container of r–134a to suction port (a) of compres***. on sanden compres***s: install jt02137 adapter in discharge port of compres***&cap port with jt03194 cap. install jt03182 adapter in suction port and using jt02108 hose&jt02179 adapter, connect gauge set and/or container of r–134a to suction port of compres***. 4. on denso compres***, connect gauge set and/or container of r–134a refrigerant to suction port (a). on sanden compres***, use appropriate fittings from fitting kit to connect gauge set directly to suction/inlet port of compres***. 5. open valves to pressurize compres***. important: do not exceed range of low pressure gauge. 6. check the following for leaks using leak detector or 50-50 mixture of soap&water: ? shaft seal ? manifold seal ? housing seals at front, rear&midsection of compres*** body ? relief valve (denso compres***) ? suction coupler schrader valve (denso compres***) leakage should not exist. repair/replace compres*** as required,&repeat test. 7. install clutch hub&cover. tighten clutch hub screw/nut to specifications. ctm67 (24sep02) 70-22 oem engine acces***ies 092402 pn=386 continued on next page air conditioning compres***s 70 23 dpsg,ouo1004,582 –19–09may02–2/2 specification denso compres*** clutch hub cap screw—torque. 14 n?m (10 lb-ft) (120 lb-in) sanden compres*** clutch hub nut—torque . 17 n?m (13 lb-ft) (150 lb-in) ctm67 (24sep02) 70-23 oem engine acces***ies 092402 pn=387 air conditioning compres***s 70 24 dpsg,ouo1004,592 –19–01mar99–1/1 disassemble&assemble compres*** clutch (denso compres***) rw21158 –un–29jul98 rw21157 –un–24jun92 a—jdg747 compres*** c—clutch hub e—pulley g—clutch coil clutch spanner d—pulley snap ring f—clutch coil snap ring h—shim b—clutch shaft bolt mount compres*** on dfrw20 compres*** holding fixture using two 6 in. x 1/4 in. eye bolts with nuts as illustrated. remove dust cover. hold clutch hub using jdg747 compres*** clutch spanner (a)/other suitable spanner wrench, and remove clutch shaft bolt (b). remove clutch hub (c). remove shims (h) from clutch hub&save for installation. remove&discard snap ring (d). remove pulley (e) using a plastic hammer/d05277st puller, jdg748 jaws,&jdg771 forcing screw pilot. disconnect clutch coil lead wire. remove&discard snap ring (f) using d05327st1 retaining ring plier, and remove the clutch coil (g). note: the bearing in the pulley is not serviceable. check pulley bearing operation. replace pulley and bearing as required. install clutch coil (g)&new snap ring (f) with flat side of snap ring down. connect clutch coil lead wire. install pulley (e)&new snap ring (d) with flat side of snap ring down. apply grease to shims (h)&install to clutch hub (c). install clutch hub&shaft bolt (b)&tighten. install dust cover. specification denso compres*** clutch hub cap screw—torque 14 n?m (10 lb-ft) (120 lb-in) 1included in jdg215 ctm67 (24sep02) 70-24 oem engine acces***ies 092402 pn=388 air conditioning compres***s 70 25 dpsg,ouo1004,593 –19–01mar99–1/1 check clutch hub clearance rw21159 –un–24jun92 note: the clutch coil is not polarity sensitive. check pulley-to-clutch hub clearance using a dial indicator. mount the gauge to the pulley as illustrated and connect a set of jumper wires from the compres*** leads to a 12v battery. rotate the pulley&check clearance in three equally spaced locations around the clutch hub. add/remove shims as required. specification denso compres*** clutch hub— clearance 0.35—0.65 mm (0.014—0.026 in) . sanden compres*** clutch hub—clearance 0.40—0.80 mm (0.016—0.031 in) tighten clutch shaft cap screw after correct clearance is obtained. specification denso compres*** clutch hub cap screw—torque. 14 n?m (10 lb-ft) (120 lb-in) sanden compres*** clutch hub nut—torque . 17 n?m (13 lb-ft) (150 lb-in) ctm67 (24sep02) 70-25 oem engine acces***ies 092402 pn=389 air conditioning compres***s 70 26 dpsg,ouo1004,594 –19–01mar99–1/1 inspect compres*** manifold (denso compres***) rw21160 –un–24jun92 a—manifold cap screw b—manifold c—manifold seal remove cap screws (a)&the manifold (b). remove&discard seal (c). inspect porting surfaces. lubricate&install a new seal (c). install manifold (b)&tighten cap screws (a). specification denso compres*** manifold cap screw—torque 26 n?m (19 lb-ft) ctm67 (24sep02) 70-26 oem engine acces***ies 092402 pn=390 air conditioning compres***s 70 27 dpsg,ouo1004,595 –19–09may02–1/3 disassemble, inspect,&assemble compres*** (denso compres***) rw78145 –un–03aug98 a—rear pins g—o-rings l—front gasket q—felt holder b—rear housing h—front pins m—snap ring r—felt c—rear gasket i—front suction reed valve n—lip seal s—front housing d—rear discharge reed valve j—front valve plate o—washer u—bushing spacer e—rear valve plate k—front discharge reed p—through bolt f—rear suction reed valve valve clean compres*** using solvent before disassembly. mount compres*** on holding fixture&remove clutch. (see disassemble&assemble compres*** clutch, this group). important: be careful not to damage sealing surfaces when removing front and rear housing. remove compres*** through-bolts using jdg2261 special hex drive. disassemble compres*** as illustrated&discard o-rings, gaskets, lip seal, snap ring,&through-bolt washers. replace parts. important: do not allow the cylinder body to separate at the middle o-ring. note: valve plates, reed valves, cylinders, and cylinder housing are not serviceable. some cylinder scuffing (light scratches) is normal. inspect valves for even wear,&cylinders for scoring or excessive wear. replace compres*** as required. 1 included in jdg215 ctm67 (24sep02) 70-27 oem engine acces***ies 092402 pn=391 continued on next page air conditioning compres***s 70 28 dpsg,ouo1004,595 –19–09may02–2/3 rw21162 –un–24jun92 rw41338 –un–16dec97 remove shaft seal snap ring (m). turn housing over and remove felt holder (q)&felt (r) from front housing (s). remove shaft lip seal (n) from front housing (s) using a small tool with 5/8 in. od. wash all parts in clean solvent&dry using moisture-free compressed air before assembly. caution: avoid direct refrigerant oil contact with skin. important: lubricate o-rings, gaskets,&lip seal using only ty22025 (r–134a) refrigerant oil during assembly. other oils could damage the compres***. apply r–134a oil to the bore of the front housing and install new lip seal (n) to the bottom of the bore using a socket. install new snap ring (m) flat side down. important: bushing spacer (u) must be in position before assembling the compres***. install pins (a)&new o-ring (g) in the rear cylinder. note: the rear valve plate is marked with an “r” and is installed face up. install parts (f—d) over the pins on the rear cylinder. install a new gasket (c) flat side down&the rear housing (b) on the rear cylinder. mount the compres*** onto the holding fixture. install pins (h)&new o-ring (g) in the front cylinder. note: the front valve plate is marked with an “f” and is installed face up. install parts (i—k) over the pins on the front cylinder. install a new gasket (l) flat side down. put jdg746 compres*** seal protector on the shaft&lubricate with r–134a oil. install the front housing (s) on the front cylinder and remove the lip seal protector. install through bolts (p) with new washers (o)&tighten evenly. specification denso compres*** housing through bolts—torque 26 n?m (19 lb-ft) ctm67 (24sep02) 70-28 oem engine acces***ies 092402 pn=392 continued on next page air conditioning compres***s 70 29 dpsg,ouo1004,595 –19–09may02–3/3 install the felt (r)&felt holder (q) using the clutch hub. install the pulley-clutch hub&check clearance. (see disassemble&assemble compres*** clutch, this group.) dpsg,ouo1004,596 –19–01mar99–1/1 remove&install compres*** relief valve (denso compres***) rw40019 –un–27aug93 caution: avoid personal injury. high pressure may exist at the discharge fitting. use proper recovery equipment to discharge system before removing relief valve. discharge system. (see discharge air conditioning system, this group.) slowly remove relief valve (a) from compres***. note: the relief valve is not serviceable. replace valve as required. install relief valve (a)&tighten. specification denso compres*** relief valve—torque. 12—16 n?m (9—12 lb-ft) charge system. (see charge air conditioning system, this group.) ctm67 (24sep02) 70-29 oem engine acces***ies 092402 pn=393 air conditioning compres***s 70 30 ctm67 (24sep02) 70-30 oem engine acces***ies 092402 pn=394 index page page a auxiliary drive (4.5&6.8l) adapter, disassemble&inspect52-3 air compres*** offset drive adapter, disassemble and drive gear, remove&install (10.5l&inspect52-3 indx 12.5l) 60-15 offset, remove&install 52-2 1 general information60-4 remove&install 52-1 remove&install (10.5l&12.5l)60-14 auxiliary drive (4.5l&6.8l) remove&install (4.5l&6.8l) 60-7 specifications 52-1 remove&install (6076 s.n. 500000--&auxiliary drive (8.1l) idler housing&idler gear, install 53-11 8.1l) 60-10 idler housing&idler gear, remove53-9 specifications 60-3 idller gear bearing, replace 53-11 spline drive shaft, remove&install (10.5l and left-hand output gear assembly, assemble 53-7 12.5l) 60-16 left-hand output gear assembly, troubleshooting chart 60-5 disassemble 53-6 air conditioning left-hand output gear assembly, install53-15 add oil to pressurized system 70-12 left-hand output gear assembly, remove 53-5 charge system 70-14 left-hand rear adapter housing, remove and check oil charge 70-10 install53-9 clutch hub, check clearance 70-25 right-hand output gear assembly, compres*** clutch 70-24 assemble53-3 compres*** leakage test 70-22 right-hand output gear assembly, compres*** manifold, inspect 70-26 disassemble 53-2 compres*** relief valve, remove and right-hand output gear assembly, install53-5 install70-29 right-hand output gear assembly, remove 53-2 compres***, disassemble&assemble 70-27 specifications 53-1 compres***, flush70-8 auxiliary drive, 6076 (500000-- ) compres***, remove&install 70-18 general information50-4 determine refrigerant oil charge 70-11 idler gear bearing, replace 50-15 diagnosing malfunctions 70-15 idler housing&gear, install 50-16 discharge system 70-7 idler housing&idler gear, remove50-13 evacuate system70-9 left-hand output gear, assemble50-11 general information70-4 left-hand output gear, disassemble 50-9 purge system 70-8 left-hand output gear, install50-19 refrigerant cautions 70-5 left-hand output gear, remove 50-8 refrigerant handling 70-5 left-hand rear adapter housing, install 50-20 retrofit r-12 to r-134a70-6 left-hand rear adapter housing, remove 50-13 specifications 70-3 right-hand output gear, assemble 50-6 system information 70-6 right-hand output gear, disassemble 50-5 volumetric efficiency test 70-20 right-hand output gear, install 50-7 air heater 25-8 right-hand output gear, remove 50-5 assembly - rear pto - john deere specifications 50-2 auxiliary idler shaft group 46-41 auxiliary idler shaft group, rear pto - john deere auxiliary pump group 46-54 assembly 46-41 primary idler shaft group 46-34 disassembly 46-23 pto primary pump group 46-50 exploded view 46-40 auxiliary drive (10.5l&12.5 l) auxiliary pump group, rear pto - john deere idler gear&bearing, remove&install 54-2 assembly 46-54 sae "a"&"b", remove&install54-3 disassembly 46-16 specifications 54-1 exploded view 46-53 auxiliary drive (2.9l) auxiliary pump, rear pto - john deere remove&install (right-hand) 51-1 access cover plate46-47 specifications 51-1 lubrication passages 46-10 ctm67 (24sep02) index-1 oem engine acces***ies 092402 pn=1 index page page b d belt tensioner diagnostics manual tensioner, adjust 40-12 engine electrical system 21-19 manual tensioner, adjust with tool 40-13 disassembly - rear pto - john deere belts, fan&alternator auxiliary idler shaft group 46-23 indx 2 adjust tension 40-15 auxiliary pump group 46-16 check 40-10 primary idler shaft group 46-28 block type coolant heater primary pump group 46-20 install . 25-3 install (saran engines) 25-5 remove 25-2 remove (saran engines) 25-4 e electric fuel pump install (john barnes) 32-13 c pressure regulating valve, install32-8 pressure regulating valve, replace 32-7 charge air cooler pressure test (bosch) 32-13 remove&install 40-5 pressure test (john barnes) 32-3 test 40-4 relief valve, adjust (john barnes)32-5 remove (john barnes) 32-6 clutch repair (john barnes) 32-8 ac compres*** 70-24 replace (bosch) 32-15 cold weather starting aids specifications 25-1 electrical connectors connectors, electrical remove blade terminals 22-6 amp . 22-15 electrical connectors deutsch 22-12 repair amp 22-15 metri-pack, pull type22-7 repair deutsch 22-12 metri-pack, push type 22-9 repair metri-pack pull type 22-7 remove blade terminals from connector repair metri-pack push type 22-9 body 22-6 repair sumitomo 22-17 sumitomo 22-17 repair weatherpack 22-3 weatherpack22-3 repair yazaki 22-19 yazaki22-19 engine electrical system coolant heater circuit malfunctions20-1 block type, install 25-3 component identification20-18 block type, install (saran engines) 25-5 crankcase oil level switch/gauge 21-16 block type, remove 25-2 diagnose malfunctions 21-19 block type, remove (saran engines) 25-4 grounded circuit 20-5 tank type, install25-6 high resistance circuit20-2 tank type, remove 25-6 key switch, test21-24 coolant temperature sen***, remove&magnetic safety switch, test 21-25 install . 40-6 open circuit 20-3 cooling system&radiator cap schematic symbols 20-15 pressure test40-7 shorted circuit20-7 cooling system specifications40-2 specifications 21-1 crankcase oil level switch/gauge starter relay, test 21-25 component function 21-16 system functional schematic reading 20-13 remove&install 22-27 test equipment 20-8 crankshaft gear assembly, rear pto - john deere test procedure 20-9 seal retainer group 46-60 visually inspect 21-18 ctm67 (24sep02) index-2 oem engine acces***ies 092402 pn=2 index page page wiring diagram (european series 300) (early remove&install 30-6 model) 20-23 fuel supply pump specifications 32-2 wiring diagram information 20-11 fuel system wiring diagram (powertech engines w/deere acces***y specifications 30-1 indx ecu) .20-28, 20-29 relieve pressure32-3 3 wiring diagram (powertech engines w/lucas fuses, checking 21-21 ecu) 20-27 wiring diagram (powertech 2.9l-8.1l)20-25 wiring diagram (powertech 2.9l-8.1l w/o ecu) 20-25 g wiring diagram (saran aez instrument panel) 20-32 gain&stability, adjust 31-13 wiring diagram (saran vdo instrument governor panel) 20-31 adjust engine speeds 31-11 wiring diagram (series 300-500 engines) 20-21 adjust gain&stability 31-13 wiring diagram (series 700 engines) 20-22 connect wiring harness31-17 wiring diagram, reading 20-14 diagnosing malfunctions 31-4 engine operation in droop mode31-14 engine speed test 31-10 engine speed installation instruction 31-15 adjust 31-11 magnetic pickup, service31-18 test . 31-10 operation in droop mode 31-14 ether starting aid, service 25-9 remove 31-18 exploded view - rear pto - john deere safety guidelines for testing 31-8 auxiliary idler shaft group 46-40 specifications 31-1 auxiliary pump group 46-53 system operation 31-2 primary idler shaft group 46-34 tests31-9 primary pump group 46-49 h f harness repair splice connector 22-33 fan&alternator belts splice wire 22-32 adjust tension 40-15 heater, fuel, remove&install 25-7 check 40-10 fan, radiator—blower & suction type install . 40-8 flywheel access cover plate, rear pto - john i deere 46-33 front pto idler shaft diameter measurements 46-6 damper&pulley, remove 47-5 inch torque values 10-2 drive gear, install 47-7 injection pump solenoid, check ("d" engines)30-1 inspect damper&pulley 47-4 instrument panel install damper&pulley 47-6 component function (saran aez panel) 21-14 pto clutch adapter (electric), remove&component function (saran vdo panel)21-12 install47-8 component function (w/john deere ecu)21-8 pto clutch adapter (mechanical), remove&component function (w/lucas ecu) 21-6 install47-12 component function (w/o ecu)21-3 specifications 47-2 specifications 22-2 fuel heater, remove&install 25-7 instrumentation (instrument panel) fuel shut-off solenoid, rotary replace (na early models)22-21 adjust . 30-7 replace (na late models w/ecu) 22-23 check . 30-5 replace (na late models w/o ecu) 22-22 ctm67 (24sep02) index-3 oem engine acces***ies 092402 pn=3 index page page replace (saran aez) 22-26 r replace (saran) (early model) 22-24 replace (saran vdo) 22-25 rack puller rp-20, check 30-2 rp-75, check 30-3 rp-75, disassemble&assemble 30-4 indx 4 k radiator&hoses 40-8 radiator cap&cooling system key switch, test 21-24 pressure test40-7 radiator fan—blower & suction types install . 40-8 rear pto - john deere l general information 46-9 inspection 46-32 lubrication passages, rear pto - john install 46-61 deere 46-10 lubrication passages 46-10 photo disclosure46-11 remove 46-11 specifications .46-4, 46-7 m rear pto - rockford/twin disc clutch adjustment, check (early) 45-33 magnetic pickup clutch adjustment, check (late) 45-34 service 31-18 clutch unit, assemble (early)45-26 magnetic safety switch clutch unit, assemble (late)45-29 test . 21-25 clutch unit, install 45-30 manual belt tensioner 40-12 diagnosing malfunctions 45-7 manual belt tensioner - using belt tension drive ring, inspect 45-32 tool 40-13 drive shaft&bearings (in-line), metric torque values 10-3 assemble45-23 drive shaft&bearings (side-load), assemble45-22 drive shaft end play, adjust45-25 o exploded view45-10 flywheel face flatness, check 45-31 oil level switch/gauge, crankcase flywheel housing face run-out, check 45-30 remove&install 22-27 general information45-7 inspect parts 45-16 pilot bearing bore, check 45-31 power take-off, disassemble 45-12 p power take-off, install 45-32 power take-off, remove 45-8 photo disclosure, rear pto - john deere46-11 specifications 45-3 primary idler shaft group, rear pto - john deere yoke, install 45-24 assembly 46-34 refrigerant disassembly 46-28 check oil charge 70-10 exploded view 46-34 determine oil charge70-11 primary pump group, rear pto - john deere proper handling70-5 assembly 46-50 r-134a cautions 70-5 disassembly 46-20 rotary fuel shut-off solenoid exploded view 46-49 adjust . 30-7 primary pump, rear pto - john deere check . 30-5 lubrication passages 46-10 remove&install 30-6 ctm67 (24sep02) index-4 oem engine acces***ies 092402 pn=4 index page page s wiring diagram european 300 series engines (early seal retainer group, rear pto - john deere model) 20-23 crankshaft gear assembly 46-60 powertech engines w/deere ecu .20-28, 20-29 indx specifications powertech engines w/lucas ecu 20-27 5 air compres*** 60-3 saran aez instrument panel 20-32 air conditioning 70-3 saran vdo instrument panel 20-31 auxiliary drive (10.5l&12.5l)54-1 series 300-500 engines 20-21 auxiliary drive (2.9l) 51-1 series 700 engines 20-22 auxiliary drive (4.5l&6.8l) 52-1 auxiliary drive (8.1l) 53-1 auxiliary drive, 6076 (500000- ) 50-2 y cold weather starting aids25-1 cooling system 40-2 yazaki connectors electrical system21-1 repair22-19 front pto47-2 fuel supply pump 32-2 fuel system acces***ies30-1 governor31-1 instrument panel 22-2 rear pto - john deere .46-4, 46-7 rear pto - rockford/twin disc 45-3 splice connector22-33 splice wire 22-32 starter relay, test 21-25 starting aid, service 25-9 t tachometer adjust (saran aez tach) 22-31 adjust (saran vdo tach)22-30 calibrate (adjustable tach) 22-28 tank type coolant heater install . 25-6 remove 25-6 tensioner, belt manual 40-12 torque values inch10-2 metric . 10-3 torque values - rear pto - john deere .46-5, 46-8 w weatherpack connectors repair. 22-3 weight values - rear pto - john deere .46-5, 46-8 ctm67 (24sep02) index-5 oem engine acces***ies 092402 pn=5 index indx 6 ctm67 (24sep02) index-6 oem engine acces***ies 092402 pn=6
